Masts, booms
We manufacture masts of different lengths and of different profiles. Check all specifications below.
Mast and boom are very important parts of a sailboat. Our products are manufactured with aluminium that characterises with lightweight and high durability to meet the needs of our clients.
Mast profiles specifications
| Width (mm) | Height (mm) | Weight (kg/mb) | Max. lenght (m) | Jx (cm⁴) | Jy (cm⁴) |
|---|---|---|---|---|---|
| 70 | 95 | 1,798 | to 9 | 39,51 | 78,5 |
| 75 | 115 | 2,165 | to 10 | 55,487 | 141,31 |
| 95 | 135 | 2,565 | to 11,5 | 106,342 | 237,159 |
| 90 | 140 | 3,445 | to 13 | 135,702 | 284,625 |
Boom profiles specifications
| Width (mm) | Height (mm) | Weight (kg/mb) | Max. lenght (m) | Jx (cm⁴) | Jy (cm⁴) |
|---|---|---|---|---|---|
| 70 | 95 | 2,228 | to 4,5 | 44,464 | 84,455 |
